Flex Panel Splitters

The Precision Flex Panel is a premium fiber optic panel that combines industry-leading density with unmatched ease of use. Its “flex” is the ability to support splitters, coexistence, and/or basic fiber patching in one platform. The Flex Panel delivers craft-friendly installation for fiber connectivity in high-density applications and will be a favorite of your technicians.

SKU: PFFLEXPANEL-1 Categories: , Tag:

Description

  • 19 or 23 inches
  • Internal slack storage
  • Front rear or rear frame mounting options
  • Houses multiple high-density splitter configurations up to 1X64
  • Front access intuitive cable routing with route diversity minimizes cable congestion
  • Single circuit front access with easy circuit identification while achieving ultra-high density
  • Adjustable field configurable clamp position allows for top, bottom, right, and left cable entry
  • Route separation for inputs / outputs provide easy circuit identification & minimal congestion
  • Can be stubbed in multiple clamping positions for multiple cable configurations
  • Can be stubbed or tie for interconnect applications
  • Easily make changes in the field as needed

Specifications

Designed to meet Telcordia GR449.
Color: black with translucent opaque cover.
Operating temperature: -20°C to +70°C (-4°F to 158°F)
Storage and shipping temperature: -40°C to +75°C (-40°F to 167°F)

Capacity

  • Coexistence ready with multiple PON options.
  • Capable of accommodating a wide variety of split ratios:

Capacity for PFFLEXPANEL

Ordering Guide

Multiple configurations – optical, patch, patch and splice, several rack units count, multiple module and cable options.

PF-19-O1-000-0EN00XFBRXN-0000-000
Rack Mount Panel 1 RU Empty

PF-23-O5-000-0EN00XFNAXN-0000-000
Empty 23 inch Panel 5 RU

PF-19-M5-000-0EN00XFNAXN-0000-000
Empty 19” Panel 5RU

PF-OM-S0311GS1GBP-000
1×8 Splitter module SCAPC

PF-OM-S0411GS6GBP-000
1X16 Splitter Module SCAPC

PF-OM-S0184RQ7LBP-000
8x1x2 Splitter Module LCUPC

PF-OM-S0183RQ3GBP-000
8x1x2 Splitter Module LCAPC

Downloads

PFFLEXPANEL Product sheet PDF
